| IPL EXP PDU8L |
|
| Memory |
|---|
| SDRAM | 512 MB |
| Flash | 512 MB |
|
| Software |
|---|
| Configuration software | Global Configurator® Plus and Professional |
| Programming software | Global Scripter®, ControlScript® Deployment Utility |
| Control apps | Extron Control, iGVE |
| Resource management software | GlobalViewer® Enterprise |
| Utilities | Toolbelt, embedded web page |
|
| Ethernet |
|---|
| Network interface controllers (NICs) | 1 |
| Connectors | 1 female RJ-45 connector |
| Data rate | 10/100Base-T, half/full duplex with autodetect |
| Protocols | ARP, DHCP, DNS, HTTP (redirect), HTTPS, ICMP (ping), IEEE 802.1X, NTP, SMTP, SNMP, SSH, TCP/IP, UDP/IP |
| Default settings | Link speed and duplex level = autodetected
IP address = 192.168.254.250
Subnet mask = 255.255.255.0
Gateway = 0.0.0.0
DHCP = off
DNS = 127.0.0.0 |
|
| Temperature sensing |
|---|
| Quantity/type | 1 thermistor port |
| Connector | (1) 3.5 mm captive screw connector, 2 pole |
| Temperature sensing range | -50.0° C to 105.0° C |
| Thermistor probe | Nominal resistance: 10 kohms
Cable length: 8 feet (2438 mm) |
|
| Switched DC power output |
|---|
| Quantity/type | 8 switched 12 VDC outputs |
| Connectors | (8) 3.5 mm captive screw connectors, 2 pole |
| Power | Maximum 60 watts total |
| Power sense | |
| Range | 0.1 watt to 60 watts |
|
| General |
|---|
| Power supply | Internal
Input: 120/240 VAC, 50/60 Hz |
| Power consumption | 1.6 watts (with no load at the DC outputs)
72.0 watts (full load) |
| Ambient temperature/humidity | Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing |
| Cooling | Convection, no vents |
| Thermal dissipation | 5.4 BTU/hr (with no load at the DC outputs)
40.9 BTU/hr (with full load) |
| Mounting | |
| Rack mount | Yes, with optional 1U rack shelf |
| Furniture mount | Yes, with optional bracket kit |
| Enclosure type | Metal |
| Enclosure dimensions | 1.7" H x 4.3" W x 8.0" D (1U high, quarter rack wide)
(42 mm H x 109 mm W x 203 mm D) |
| Product weight | 2.2 lbs (1.0 kg) |
| Regulatory compliance | CE, C-Tick, c-UL, FCC Class A, ICES, UL, VCCI
Complies with the appropriate requirements of RoHS, WEEE |
| Product warranty | 3 years parts and labor |
| NOTE | All nominal levels are at ±10%. |
|
| NOTE | Specifications are subject to change without notice. |
|
| (6193-D4) |
