| RCP 401 Series |
|
| Communication |
|---|
| USB storage port | 1 front panel female USB Type A (max. current 1.5A) |
| USB control port | 1 rear panel female USB Type C, connects to the control port on the SMP 401 |
| USB standards | USB 3.1 Gen 1 |
|
| USB device ports |
|---|
| Number/signal type | 1 USB hub |
| Connectors | 1 female USB 3.1 Type A (for storage) |
| Maximum built-in USB hubs | 1 |
| Minimum built-in USB hubs | 1 |
| Available USB power | 1.5 A |
|
| General |
|---|
| Power supply | External
Input: 100-240 VAC, 50-60 Hz
Output: 12 V, 1.5 A, 18 W |
| Power consumption | |
| Device | |
| RCP 401 D | 9.1 W |
| RCP 401 EU | 8.6 W |
| RCP 401 MK | 9.1 W |
| Device and power supply | |
| RCP 401 D | 11.2 W |
| RCP 401 EU | 10.1 W |
| RCP 101 MK | 11.1 W |
| Temperature/humidity | Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing |
| Cooling | Convection, no vents |
| Thermal dissipation | |
| Device | |
| RCP 401 D | 5.3 BTU/hr |
| RCP 401 EU | 3.7 BTU/hr |
| RCP 401 MK | 5.3 BTU/hr |
| Device and power supply | |
| RCP 401 D | 12.6 BTU/hr |
| RCP 401 EU | 9.0 BTU/hr |
| RCP 101 MK | 12.4 BTU/hr |
| Mounting | |
| Furniture or wall mount | |
| RCP 401 D | Mounts to standard 1-gang US enclosures or to surfaces with included mud ring |
| RCP 401 EU | Mounts to standard 1-gang enclosures with 60 mm mounting centers. Device module fits Flex55 mounting frames that accept 55 mm x 55 mm modules. |
| RCP 401 MK | Mounts in a standard MK Wall Frame for United Kingdom Junction Boxes |
| Enclosure type | High impact plastic blend, metal mounting bracket |
| Enclosure dimensions | |
| RCP 401 D | Fits the opening in a standard 1-gang US wallplate |
| Wallplate | 4.50" H x 2.79" W x 0.38" D
(114 mm H x 71 mm W x 9.7 mm D) |
| Device | 2.7" H x 1.6" W x 1.5" D
(69 mm H x 41 mm W x 37 mm D)
(Depth includes connectors and buttons. Allow enough depth in the wall or furniture for the device plus cable clearance.) |
| |  |
| RCP 401 EU | Fits the opening in a 1-gang EU, Jung AS 500 wallplate, Extron Flex55 mounting system, or other European frame that accepts 55mm x 55mm modules |
| Wallplate | 3.17" H x 3.17" W x 0.51" D
(81 mm H x 81 mm W x 13 mm D) |
| Device | 2.2" H x 2.2" W x 1.5" D
(55 mm H x 55 mm W x 37 mm D)
(Depth includes connectors and buttons. Allow enough depth in the wall or furniture for the device plus cable clearance.) |
| RCP 401 MK | Mounts in a standard MK Wall Frame for United Kingdom Junction Boxes |
| Wallplate | 3.39" H x 3.39" W x 0.40" D (1-gang)
86 mm H x 86 mm W x 10 mm D) |
| Device | 2.2" H x 2.2" W x 1.5" D
(55 mm H x 55 mm W x 37 mm D)
(Depth includes connectors and buttons. Allow enough depth in the wall or furniture for the device plus cable clearance.) |
| |  |
| Product weight | |
| RCP 401 D | 1.0 lb (0.5 kg) |
| RCP 401 EU | 1.0 lb (0.5 kg) |
| RCP 401 MK | 1.0 lb (0.5 kg) |
| Regulatory compliance | CE, C-Tick, c-UL, FCC Class A, ICES, RoHS, UL, WEEE |
| Accessibility | Complies with the appropriate requirements of Section 508 of the Rehabilitation Act (29 U.S.C. 794d). |
| Product warranty | 3 years parts and labor |
| Everlast power supply warranty | 7 years parts and labor |
| NOTE | All nominal levels are at ±10%. |
|
| NOTE | Specifications are subject to change without notice. |
|
| (4549-D1) |
